Wiiboox Reeyee X7 High Scanning Accuracy Laser 3D Large Scanner
Delivery Time: 15 To 20 Working Days
Wiiboox Reeyee X3 handheld laser 3D scanner is not only light and portable but also very easy to operate. You do not need to do external clamping positioning before scanning.
PRODUCT OVERVIEW
Light Body, Easy Operation
Wiiboox Reeyee X3 handheld laser 3D scanner is not only light and portable but also very easy to operate. You do not need to do external clamping positioning before scanning.
High Accuracy, High Speed
Accuracy up to 0.03mm. High speed scanning: 240,000 points/s.
Original HOI Scanning Technology
The original HOI (hybrid of optics and inertia) scanning technology enables a substantial increase in accuracy and reliability of the point cloud registration, especially for the large workpiece scanning.
Almost Unlimited 3D Scanning
Wiiboox Reeyee X3 Laser 3D Scanner is adaptable to almost every 3d scanning tasks, regardless of the size, texture, color of the object and the influence of environment.
Customer Cases
Based on the R & D team's experience in 3D scanning industry, Wiiboox Reeyee X3 Laser 3D Scanner, is now widely used in aerospace, shipbuilding, automotive, medical, art & design, scientific research and many other fields.
| Product Name | Wiiboox Reeyee X7 High Scanning Accuracy Laser 3D Large Scanner |
|---|---|
| Weight | 0.95 Kg |
| Scan Mode | Handheld |
| Scan Precision | 0.02 mm+0.06 mm/m |
| Scan Range (Fixed Type) | 300×250mm |
| Scan Range (Professional) | 100-8000 mm |
| Sensor Resolution | 0.05 mm |
| Scan Speed | 480, 000 points/s |
| Coded Transmitter | USB 3.0 |
| Shooting Distance | 300mm |
| Operating Temperature | -10-4 0"C |
| Dimensions | 130 x 90 x 310 mm |
| Manufacturer | Wiiboox |
| Country of Origin | China |
