PRODUCT OVERVIEW

The world's smallest 50,000 lumens laser projector featuring Native 4K Resolution. Stunning image quality in a compact body, designed for the most demanding large-venue projections.

50,000 lm^*1 Native 4K Color-Rich Images for a Breathtaking Viewing Experience

Unleashes 50,000 lm^*1 at Native 4K for emotionally immersive projection with newly developed laser engine expanding color-gamut by 114%^*3 using an additional red laser for breathtaking image performance

Versatile All-in-One Design Streamlines On-Site Workflow

Convenient all-in-one body packs 50,000 lm^*1 into PT-RQ32K’s compact footprint for easy installation, while Smart Projector Control Ver. 2.0^*4 with NFC^*5 and Remote Preview enable swift setup even in Standby mode

Original Cooling System Secures Projection Stability

Redesigned airflow path, cooling system, and finless radiator reinforce reliability at events. Dynamic Digital Control precisely regulates red laser output and cooling for supremely consistent image quality

Awe-Inspiring Color, Brightness, and Resolution

The PT-RQ50KE represents a milestone in projection technology. Serving flawless Native 4K (4096 x 2160) images with a laser engine that combines one red laser and two blue lasers operating at different wavelengths, light output is doubled from the same footprint as our 26,000 lm PT-RQ32K 4K projector. Deployed at sporting events, arena concerts, outdoor mapping attractions, or museum exhibitions, the PT-RQ50K’s refined power will exceed the highest expectations.

Newly Developed Laser Engine Expands the Color Gamut

An all-new laser engine expands color-gamut to 114 % of our current PT-RQ32K flagship, achieving lush, vibrant hues that pull audiences into the artist’s world. A new red laser enhances two blue lasers, which output light at different wavelengths for high color accuracy. Combined with digital frame-by-frame control to manage light output according to the scene’s contrast and brightness requirements and dedicated red-laser cooling to precisely control temperature, the PT-RQ50KE attains vivid reds and deep, natural blues for spectacular on-screen color expression.

Compact All-in-One Body with Built-in Cooling

The PT-RQ50KE’s laser engine and optical drive doubles output power from the same compact footprint as the PT-RQ32K. A redesigned airflow path and new finless radiator boosts the efficiency of the liquid cooling system, while a separate cooling for the red laser is regulated by Dynamic Digital Control for excellent image consistency and high reliability. Space-saving design with integrated cooling systems bring the logistic efficiencies of all-in-one projection to large-venue staging, saving operators time and money.

Remote Preview Saves Time and Unnecessary Stress

Newly introduced within Multi Monitoring & Control Software and also accessible via web browser, Remote Preview allows projectionists to check the content being received by the projector via a Wi-Fi®- or LAN-connected laptop. It works with the projector in Standby, with the shutter on, or when direct sunlight makes inspecting on-screen images difficult. It gives a chance to fix errors between the source and projector before setup is completed.

Built-in Upgrade Kits for Geo Pro Software Now Preactivated

With the PT-RQ50KE, upgrade features for Geometry Manager Pro are built into the software and do not require paid activation. Simply download and install Geo Pro to a PC to simplify advanced multi-screen geometric adjustments. Built-in capabilities include uniformity correction and Auto Screen Adjustment for automatic and simultaneous calibration of multiple screens (including curved-screen correction) using a compatible camera. These features expedite edge-blending and color-matching in mapping applications with automatic calibration for black level, brightness uniformity, and stacking.

Geometric Adjustment with Free Grid Correction via Remote Control

Free Grid is a function in Geometric Adjustment that enables convenient grid-based image adjustment using the projector’s remote controller. Grid resolutions of 2 x 2, 3 x 3, 5 x 5, 9 x 9, or 17 x 17 can be projected and areas of the image reshaped or geometrically altered to compensate for screen distortions. This correction is easily performed by adjusting control points located at grid-line intersections. Move freely between grid resolutions to achieve the desired level of granularity without losing work progress. This clever data-saving function allows technicians to smoothly create a distortion-free projection in a wide range of installation situations.

Remote App with NFC Function*1 and Projector Auto-Focus via Smartphone Camera

Smart Projector Control app for Android™ and iOS now includes Near Field Communication (NFC) function to instantly pair smartphone to projector just by touching them together. Once linked, the app accesses an information settings menu that’s readable and writable*2 for easy adjustment without turning on the projector. As well as showing data and allowing certain settings to be changed, the app features an auto-focus function*3 that uses the smartphone’s camera and app UI to achieve fast yet precise image focus.

New Information Monitor

To further simplify setup and operation of the PT-RQ50KE, an Information Monitor is located on the side panel adjacent to terminals and physical controls. The monitor provides menu-based navigation for smooth setup of Projector ID and basic network configuration. It also shows projector status including temperature, runtime, and active signal data, as well as error codes should a problem be detected.

Dual Power Supplies Save Time During Setup [Japan/U.S. Only

The PT-RQ50KE equips dual power supplies and supports 200–240 V current for full-brightness projection as well as 100–120 V at a lower brightness for setup and calibration. This feature is of incalculable value at events where installation deadlines are tight (such as trade shows) as the PT-RQ50KE can be set up and adjusted on regular mains power before high-current power is rolled out. No more wasted time on unforeseen holdups—this keeps your team on schedule as event infrastructure comes together around you.

Dedicated Lenses Cover All Throw-Ratios

An exclusive new lineup of optional lenses for the PT-RQ50KE provides gapless throw-ratio coverage from 1.11–1.70:1 to 4.97–7.76:1, adapting projections to suit the installation site. All six models support powered zoom, lens-shift, as well as lens memory and lens ID for easier on-site adjustments. AFO (Active Focus Optimizer) feature optimizes focus based on content APL, keeping images sharp and in focus.

Reliable Red-Laser Performance for Intense Color

Red lasers demonstrably heighten color expression. However, implementation of the technology has been a challenge due to the laser’s sensitivity to temperature fluctuation. Panasonic innovates a highly stable red-laser drive that digitally controls light output within precise parameters frame-by-frame using Dynamic Digital Control and an independent cooling system. The additional red laser is key to the ’s vivid red reproduction and a superior RGB balance.

Shielded Laser Drive with Finless Radiator

Hermetically sealed DMD block, shielded laser drive, and filterless cooling system is reinforced by a new finless radiator that improves cooling efficiency by as much as 30 % over previous implementations while protecting critical components from dust intrusion. The projector exceeds common international dustproofing guidelines and is manufactured in Japan to extremely rigorous quality control standards. Business operators can expect up to 20,000 hours* of reliable maintenance-free projection at full brightness.

Solid-State Laser Modules with Failover Circuitry

The SOLID SHINE Laser drive groups laser diodes into discrete modules. In the unlikely event one single diode in a module goes out, Failover Circuitry enables the diodes in the affected series to be bypassed—the remaining, functional diodes continue to operate with imperceptible loss in brightness. If a laser diode fails in other laser projectors, the whole module goes down and the brightness loss is so great that the projector must be taken offline. Panasonic laser diode failover technology adds yet another layer of insurance for events projection when image presentation must be maintained.

Backup Input Guarantees Picture Display

If the primary signal is disrupted, the projector switches to a backup input*1 in just 0.3 seconds at the fastest*2, so image display is maintained when projection mustn’t be interrupted. No screen-blanking occurs during backup input-switching.
